| Dimension | 11000mm-16000mm x 3000-3500mm x 1650 mm (Standard or Customized ) |
| Loading Capatity | 80 T – 150 T |
| Axle | 13T/16T, BPW/FUWA/Chinesebrand |
| Rim | 6.5-20/7.5-20/8.00-20/8.5-20 |
| Tire | 8.25R20/10.00R20/11.00R20/12.00R20 |
| Suspension | Tri-axle Mechanical suspension or Air Suspension (Chinese brand or BPW brand) |
| King Pin | JOST brand 2.0 or 3.5 inch (bolted or welded type) |
| Landing Gear | JOST brand or Chinese brand 28 Tons |
| Main Beam | Height:450mm-580mm Q354B steel |
| Side Beam | 16mm-30mm “I” Steel |
| Ladder | Manually operated or Hydraulic type |
| Gooseneck | Optional |
| Brake Chamber | WABCO (brake system) |
| ABS | Optional |
| Light | LED light |
| Voltage | 24V |
| Socket | 7-Pin Socket |
| Surface Coating | Sandblasted, anti-rust chassis surface is avaible with 1 layer of anticorrosive primer and 2 layers of top coats. |
| Customization | Customized heavy duty low bed trailer Available , this specification just for you reference |
