| Model | SX42594X404T |
| Make | SHACMAN |
| Drive type | 6×4 |
| Weight | |
| Complete kerb mass(kg) | 9,500 |
| GCW(kg) | 49,000 |
| Dimensions | |
| Max.length(mm) | 7,625 |
| Max.width(mm) | 2,490 |
| Max.height(mm) | 3,980 |
| Wheel base(mm) | 3,975+1,400 |
| Performance | |
| Max.speed(km/h) | 88 |
| Engine | |
| Make | WEICHAI |
| Model | WP13NG460E61 |
| Power(kW/Hp) | 338/460 |
| Displacement(L) | 12.54 |
| Max.torque(N.m/rpm) | 2,300/1,100-1,500 |
| Emission Standard | E-Ⅵ |
| Transmission | |
| Make | FAST GEAR |
| Model | F16JZ24A |
| Type | AMT with overdrive |
| Gear Shift | 16 forward and 2 reverse |
| Ratio | F: 14.129 11.703 9.766 8.089 6.685 5.537 4.521 3.745 3.125 2.588 2.160 1.789 1.479 1.225 1.000 0.828 R: 12.999 10.767 |
| Retarder | |
| Make | FAST GEAR |
| Model | FHB400 |
| Type | Hydraulic retarder, in parallel |
| Clutch | |
| Make | EATON |
| Diameter(mm) | φ430 |
| Brakes | |
| Type | Drum braking |
| Service brake | With dual-circuit compressed air brake |
| Park brake | Power spring brake acting on rear wheel |
| Auxiliary brake | WABCO EBS with 6 channels+ASR+ESC+LDWS |
| Steering | |
| Type | ZF technology, integral inner circulation power steering |
| Chassis | |
| Frame dimension | (970-850)*270, with single layer |
| Suspension | |
| Front Suspension | Semi-elliptic springs suspension |
| Rear Suspension | Pneumatic suspension with 8 airbags with ECAS adjusting system |
| Axles | |
| Make | MAN |
| Front axle | 7,500kg |
| Rear axle | 11,500kg*2= 23,000kg |
| Single reduction widen driven axles | |
| Ratio | 4.625 |
| Tires | |
| Model | Front tires: 12R22.5*2, radial tires Rear tires: 425/65R22.5*4, super single tires Spare tire: 425/65R22.5, super single tire |
| Rim | Aluminum |
| Fuel tank | |
| Tank capacity(L) | 212L*8(installed behind the cabin)+80*4(installed by the right side of chassis)=2,016 L |
| Theoretical range mileage(km) | Approximately 760km |
| Cabin | |
| Type | SHACMAN X5000, Lengthened high roof |
| Equipments | Cabin with top spoiler, Mechanical skylight, Pneumatic suspension cabin, Automatic A/C, Two bunker, Rear windows, Electronical rear mirrows heating system, Electronical reversal cabin, Electronical windows lifting system, Driver & co-pilot seats with air-suspension, Trailer independence braking device, Multi-function steering wheel, Multi-media LED screen, TELEMATICS management system, Central lock, LED front daylights, Radio with MP3 format, Fibra-glass front bumper,TPMS. |
| Fifth wheel | JOST 50#(king-pin 2 inches) |
| Others | Fleetguard air filter, WABCO valves, Reversing buzzer, Aluminium air reservoirs,High-end anticorrosion |
