| Model | SX331862306C | |
| Drive type | 8×4 | |
| Type | Dump Truck | |
| Weight | ||
| Complete kerb mass(kg) | 17,500 | |
| Max.total mass (kg) | 70,000 | |
| Performance | ||
| Max.speed (km/h) | 80 | |
| Max.gradeability(%) | 35 | |
| Dimensions | ||
| Max.length | 9,400 | |
| Max.width | 2,490 | |
| Max.height | 3,450 | |
| Wheel base(mm) | 1,800+2,975+1,400 | |
| Rear overhang(mm) | 850 | |
| Engine | ||
| Make | CUMMINS | |
| Type | M13E5 520 | |
| Rated Output (HP) | 382/520 | |
| Torque(N.m)/rpm | 2,500/900-1,400 | |
| Rated speed(r/min) | 1,800 | |
| Displacement(ml) | 12,500 | |
| Emission Standard | Euro Ⅴ | |
| Transmission | ||
| Make | FAST GEAR | |
| Type | 13JSDX240T | |
| Control type | Manual | |
| Gear ratios | F: 15.53 12.22 9.39 7.33 5.73 4.46 3.48 2.74 2.10 1.64 1.28 1.00 0.78 R:14.86 3.33 | |
| PTO | QH50 | |
| Retarder | ||
| Make | FAST GEAR | |
| Model | FHB400 | |
| Type | Hydraulic retarder, In parallel | |
| Clutch | ||
| Make | EATON | |
| Diameter(mm) | φ430 | |
| Braking system | ||
| Type | Drum | |
| Service brake | Dual-circuit compressed air brake | |
| Park brake | Power spring brake acting on front & rear wheel | |
| Auxiliary brake | JACOB | |
| Frame | ||
| Type | 850×300(8+7), with double layers | |
| Suspension | ||
| Front | Semi-elliptic springs suspension | |
| Rear | Trapezoidal leaf springs suspension with stabilizer bar | |
| Steering system | ||
| Type | ZF technology Integral inner circulation power steering | |
| Axles | ||
| Front axle | MAN 9,500kg*2 | |
| Rear axles | 16,000kg*2= 32,000kg widen axles | |
| Double reduction driven axles with inter-wheel differential and differential lock with hub reductors | ||
| Ratio | 5.92 | |
| Tires | ||
| Type | 12.00R24 | |
| Parttern | Front Mixed & Rear Transverse | |
| Numbers | 12+1 | |
| Fuel tank | ||
| Tank capacity(L) | 300L | |
| Material | Aluminum | |
| Electrics system | ||
| Type | 24V | |
| Battery | 180Ah | |
| Cabin | ||
| Model | SHACMAN X5000, flat roof | |
| Standard equipments | Rear window, Hydraulic suspension for cab, A/C, Pneumatic suspension driver seat seat , One bunker, Electric reversal cab, Metal bumper, Electric windows lifting system, Cruise control system, Central lock, Multi-media LED screen, Intercooler protector. | |
| Others | WABCO valves, Aluminum air reserviors, Reversing buzzer, Front&Rear lights protectors, Taillight of chassis,Oil bath air filter | |
| Dumper body | ||
| Lifting system | DEPKAALER ϕ181 Front lifting system | |
| Body type | U-type, integral dumper body with manganese, bottom: 16mm side: 12mm | |
| Body dimensions(mm) | 6,500×2,300×1,600 | |
| Volume(m3) | 23.92 |
