| Main Beam | Height:500mm, upper plate is 16mm,middle is 8mm(double+three plate), down plate is 18mm,material is Q345B steel |
| Axle | 3 axles, 13T/16T/20T, FUWA/BPW Brand |
| Landing Gear | JOST Brand |
| King Pin | JOST 2.00 OR 3.5 inch |
| Suspension | Mechanical suspension (Germany Type Or America Type) or Air suspension |
| Spring Leaf | 90(W)mm*13(Thickness)mm*10 Layer(especial for exporting market) |
| Break Systerm | WABCO RE 6 relay valve ; T30/30+T30 Spring brake chamber(TKL brand);Two pieces of 45L air tanks or China brand |
| Rim | 9.00-22.5/8.00-20/8.5-20 |
| Tire | 12.00R22.5/315 80R22.5 / 11.00R20 / 12.00R20 Brand can be optional |
| ABS | Optional |
| Valve | Wabco valve |
| Light | LED light (especial for exporting market) |
| Voltage | 24V |
| Receptacle | 7ways (7 wire harness) |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime,2 coats of final paint |
| Tool Box | One piece ,1m*0.5m*0.5m(Size can be choose freely)(Equipped with 1 unit Tirespanner, 1 unit gudgeon sleeve and i unit cranking bar) |
| Shipping Terms | By bulk cargo carrier or RORO, the trailer size can be design according to your special requirement, the tractor truck can be 6*4 model. |
